2.8 inch glass capacitive touch sensor panel with TFT
| Product Name | 2.8 Inch Capacitive Touch Panel |
| Material | Sodalime, Chemical Reinforcement |
| Cover Glass Dimension | 69.2±0.1*50±0.1 mm |
| Cover Lens VA | 52.2±0.2*43.8±0.2 mm |
| COVER LENS Thickness | 0.7 mm |
| SCA | 0.2 mm |
| ITO GLASS Thickness | 0.55 mm |
| Total Thickness | 1.45±0.1 mm |
| FPC | 6 PIN |
| Operating Voltage | 2.8 V-3.3 V |
| Interface Voltage | 2.8 V-3.3 V |
| Resolution | 240*320 |
| Interface | FT6336G |
| Transmittance | ≥85% |
| Surface Hardness | 6H |
| Operating Environment | -20℃~+70℃,≤90%RH |
| Storage Environment | -30℃~+80℃,≤90%RH |
| General Tolerance | ±0.2 mm |
Glass touch screens are widely used in electronic products, which not only enable human-machine interaction, but also have many advantages and unique qualities.
Firstly, the glass touch screen itself has excellent physical properties, such as high hardness, high transparency and high strength. These properties make the glass touch screen in use to maintain a relatively good stability and durability, and can withstand most human finger pressure, reducing the rate of damage to the touch screen.
Secondly, glass touch screens do not cause mis-touching due to the electrical charge of human fingers, greatly reducing the risk of operational errors. The spacing between the glass touchscreen and the display is also very small, reducing reflections and glare and providing superior visual effects when in use.
In addition, the glass touch screen has excellent flatness for an ultra-smooth touch and has a significant texture that adds to the user experience. It is also oil and fingerprint resistant, keeping the screen clean and shiny.
In electronics, the glass touch screen is irreplaceably superior. Compared to traditional mechanical buttons, it is more in line with the world's general trend of not only being more aesthetically pleasing, but also reducing the thickness and size of products, supporting the development of thin, light, small and high-bright electronics. Moreover, glass touch screens are more convenient to interact with, allowing users to operate electronic devices in a more direct and user-friendly way by touching the screen.
