PCAP Touch Screen Panel 5 Inch Capacitive Touch Lcd Screen Tft Lcd Module Glass Overlay Kit Touch Panel for Industrial HMI

Name: PCAP Touch Screen Panel 5 Inch Capacitive Touch Lcd Screen Tft Lcd Module Glass Overlay Kit Touch Panel for Industrial HMI
Brand: WIWOTOUCH
SKU: 226048347

5 inch capacitive touch screen Features:
Multi-touch: Support multi-touch, improve user experience, support gesture recognition.
High light transmittance: The use of high-quality glass material, light transmittance of up to 85%, to ensure clear display.
High sensitivity: Capacitive touch technology, fast response speed, accurate touch.
Strong durability: The surface is scratch-resistant glass and supports IK protection class, suitable for industrial environment.
Customization: Different interfaces (I2C/USB/RS232), glass thickness, cover LOGO, etc. can be customized according to requirements.
Strong anti-interference ability: suitable for complex electromagnetic environment, stable and reliable.
Glove touch: Supports water drop, waterproof mode, can be used in gloves or wet environment.
5.5 inch touch projected capacitive touch panel，cover glass 0.7mm, 1-10 points multi touch. We also provide the customize service.

Product Introduction

PCAP Touch Screen Panel 5 Inch Capacitive Touch Lcd Screen Tft Lcd Module Glass Overlay Kit Touch Panel for Industrial HMI

Product Description

Product Name	5 Inch Capacitive touch panel
COVER LENS Thickness	0.7 mm
ITO GLASS Thickness	0.4 mm
Total Thickness	1.475±0.15 mm
Material	Sodalime, Chemical Reinforced
Lens Color	Black
FPC	6PIN
IC Model	FT7311
Operating Voltage	2.8V-3.3V
Interface Voltage	2.8V-3.3V
Transmittance	≥85%
Surface Hardness	6H
Operating Environment	-20℃~+70℃,≤20～85%RH
Storage Environment	-30℃~+80℃,≤10～85%RH

Brand Name

WIWOTOUCH

Model Number

240ACTL050GG

Application

Industrial

Interface

IIC

Type

Capacitive

Length

128.6mm

Diagonal Screen Size

5inch

Width

85.4mm

Features

Black

Drive IC

FT7311

Product Name

5 Inch Capacitive Touch Panel

Cover Glass Dimension

128.6±0.2*85.4±0.2 mm

Cover Lens VA

108.7*65.4 mm

Structure

Glass+Glass+FPC

Certificate

RoHS, ISO9001, Reach

Touch type

Multi Touch

Interface of Touch Panel

IIC

Application

Smart/Industrial/medical etc

Warranty

1 Year

Shipment method

DHL FEDEX UPS EMS TNT

WIWOTOUCH P-CAP & TFT Manufacturer

• PCAP size from 0.6"-43"
• Multi Touch (The touch screen can be customized according to your needs.)
• Optical Bonding service/Air bonding
• LCD Interface: HDMI/RGB/MIPI/LVDS
• PCAP Interface: IIC/USB interface
• CTP can be Customized with cover glass surface treatment process AG(anti-glare), AR(anti-reflective), AF(anti-fingerprint), Water-proof, Glove Touch
• Support touch with 0.55 mm-12 mm cover glass.
• Support operating temperature: -30℃-90℃.

Company Introduction

Fujian WIWO Electronic Technology Co., Ltd. is a modern science and technology company who professionally researchers, manufactures and designers of Projected Capacitive Touch Panel / Screen. Our main product structure includes Glass + Glass, Glass+Film, Glass + film + film, fully lamination, car capacitive touch screen, 3D touch screen and large size touch screen. At present, our company has been certificated by IATF16949:2016, ISO9001:2015, REACH, RoHs and ISO14001. And, we have international advanced equipments, 800 square meters of 100 grade dust-free workshop and 2000 square metres thousands grade dust-free workshop,in order to provide customers with good quality products.
