4 Inch LCD industrial Display Module Capacitive Touch Screen 480*800 Resolution Capacitive Touch Panel

4 Inch LCD industrial Display Module Capacitive Touch Screen 480*800 Resolution Capacitive Touch Panel

The 4-inch capacitive touch screen,due to its small size, responsive and intuitive operation, is widely used in a variety of portable and embedded devices.

Product Introduction

4 Inch LCD industrial Display Module Capacitive Touch Screen 480*800 Resolution Capacitive Touch Panel

9 capacitive touch screen


Product Name4 inch capacitive touch panel
Cover Lens Thickenss0.7mm
Sensor Thickness 0.425mm
Other Tolerance±0.2mm
FPC6 pin
Interface TypeIIC
Transmittance≥85%
surface hardnsee≥6H
Operating Environment-20℃~+ 70℃
Storange Environment -30 ℃~+80℃


Model Number
CSB040FF012
Application
play station portable
Interface
IIC
Type
Capacitive
Length
59mm
Diagonal Screen Size
4 inch
Width
101mm
Features
small, ≤IK10
Drive IC
FT5336
Cover Glass Dimension
59±0.1*101±0.1mm
Cover Lens VA
52.84±0.2*87.4±0.2mm
Sensor Dimension
58.6±0.2*100.6±0.2mm
Resolution
480*RGB*800
Structure
G+FF
Interface of Touch Panel
IIC
Certificate
RoHS Reach ISO9001
Shipment
DHL\UPS\FEDEX\EMS\POST.etc
Warranty
1 Year
Touch panel
Support Customization


4-inch capacitive touch screen features:

Size: The screen measures 4 inches diagonally and is compact for portable devices

Touch mode: projected capacitive touch, support multi-touch (generally 5~10 points), high touch sensitivity

Display effect: often with high-definition LCD, resolution such as 480×800, 720×1280, clear display

Structure type: Common G+G (glass + glass), G+F (glass + film) structure, support custom cover plate (LOGO, window opening, etc.)

Durability: Support scratch resistance and wear resistance (surface hardness ≥6H), some support waterproof/glove touch

Interface type: Common interfaces include I2C/USB, etc., easy to connect with the main control board /MCU

Driver compatibility: Compatible with multiple operating systems, such as Android, Linux, and Windows, and supports customized drivers

Working environment: Wide operating temperature range, can be customized -20~+70℃ or wider temperature specifications

Product application

Please let me know requirements and we will provide  you with the best solution!



4 Inch LCD industrial Display Module Capacitive Touch Screen 480*800 Resolution Capacitive Touch Panel



Our Services

We offer customized solutions which are prapreed according to customer requirements.Our touch  screens mag be produced in a selected shape ,color , size of cover giass , touch IC ,thickness , packing,corner with logo and other additional element as per specification provided by the client.

  • SIZE
  • SHAPE
  • COLOR
  • TOUCH IC
  • THICKNESS
  • LOGO
  • PACKING

Treament customizion:Anti-glare, Anti-fingreprint , Anti-reflective , Anti-UV , Antibacteral ,Waterproof, Vandal-proof , 3D curve sueface IC: Atmel , ILITEK ,EETI , CYPRESS , etc4 Inch LCD industrial Display Module Capacitive Touch Screen 480*800 Resolution Capacitive Touch Panel
