Name: 7 Inch FT5426 IIC Touch Screen 7 PCAP Projected Capacitive Touch Screen touch screen for tft lcd module
Brand: WIWO
SKU: 205006724

7 Inch FT5426 IIC Touch Screen 7 PCAP Projected Capacitive Touch Screen touch screen for tft lcd module

Product Description

Product Name	7 Inch Capacitive touch panel
Material	Asahi Dragon Trail
COVER LENS Thickness	1.1±0.1 mm
ITO GLASS Thickness	0.7±0.1 mm
SCA	0.2 mm
Total Thickness	2±0.1 mm
Other Tolerance	±0.2 mm
Interface Type	IIC
FPC	8 PIN
Operating Voltage	2.8 V-3.3 V
Interface Voltage	2.8 V-3.3 V
IC Model	FT5426
Transmittance	≥85%
Surface Hardness	6H
Operating Environment	-20℃~+70℃,≤90%RH
Storage Environment	-30℃~+80℃,≤90%RH

Model Number

CSB070GG182

Application

POS

Interface

IIC

Type

Capacitive

Length

195.6mm

Diagonal Screen Size

7 inch

Width

130mm

Features

Black

Drive IC

FT5426

Product Name

Capacitive Touch Panel

Cover Glass Dimension

195.6±0.1*130±0.1 mm

Cover Lens VA

154.44±0.2*86.23±0.2 mm

Structure

Glass+Glass+FPC

Touch type

Multi Touch

Interface of Touch Panel

IIC

Shipment

DHL FEDEX UPS EMS TNT

Application

Smart Home, Industrial, Medical, etc

Certificate

RoHS, ISO9001, Reach

Warranty

12 Months

7 inch capacitive touch screen Application scenarios:

1. Industrial control

Device human machine interface (HMI), such as PLC control panel

Industrial automation control system

Production line data monitoring

2. Medical equipment

Medical monitor (blood pressure, ECG monitor, etc.)

Ultrasonic diagnostic equipment

Medical information terminal

3. Smart home

Intelligent access control system

Smart home appliance control panel (such as smart refrigerator, smart speaker)

Home automation control terminal

4. Automotive electronics

In-car navigation (GPS) and infotainment system

Vehicle dashboard

Electric vehicle charging pile display

5. Retail and self-service terminals

POS (Cash Register terminal)

Self-service inquiry machine, ticket machine

Express cabinet, number machine

6. Intelligent instrumentation

Intelligent detection equipment

Electronic measuring instrument

Internet of Things terminal devices

7. Portable devices

Handheld terminal (PDA, scanner)

Electronic reader

Field survey equipment

Company Introduction

Fujian WIWO Electronic Technology Co., Ltd. is a modern science and technology company who professionally researchers, manufactures and designers of Projected Capacitive Touch Panel / Screen. Our main product structure includes Glass + Glass, Glass+ Film, Glass + film + film, fully lamination, car capacitive screen, 3D touch screen and large size touch screen panel. At present, our company has been certificated by IATF16949:2016, ISO9001:2015, REACH, RoHs and ISO14001. And, we have international advanced equipments, 800 square meters of 100 grade dust-free workshop and 2000 square metres thousands grade dust-free workshop,in order to provide customers with good quality products.

Our Advantage

The company has a R & D team which is young, full of energy and dare to try; completely master the technology of capacitive touch panel through independent research and development and has the ability to make new products according to the clients'requirements. Therefore, we have established the technical advantages in the industry of touch panel.

1,Custom service: shape, color, size of cover glass, thicknesses, logo icon, and other additional element according to the specifications provided by the customer.

2,Special Treatment :AG/AG/AF ,Water-proof,With glove touch.
3,Touch screen structure:Glass+Glass, Glass+Film, Glass+Film+Film.
4, Advanced machine:the advanced equipments from Japan and Taiwan.
5,Touch controller: ilitek, EETI ,Goodix, Focaltech and so on.
