custom pcap 7 Inch touch screen
The pcap (projected capacitive) technology ensures accurate and responsive touch input, allowing users to interact with the screen seamlessly. This technology is known for its high sensitivity and precision, making it a popular choice for touch-based interfaces.
The pcap (projected capacitive) technology ensures accurate and responsive touch input, allowing users to interact with the screen seamlessly. This technology is known for its high sensitivity and precision, making it a popular choice for touch-based interfaces.
The custom design of this 7-inch touch screen allows for flexibility in integration into various devices and systems. Whether it's for a handheld device, a kiosk, or an industrial machine, this touchscreen can be tailored to meet specific requirements.
In addition, the thin glass panel not only enhances the overall aesthetics of the device but also helps to reduce weight, making it more portable and convenient to use.
Overall, the custom pcap 7-inch touch screen with 0.7 mm glass is an excellent choice for those looking for a durable, high-performance touchscreen solution that offers excellent visual quality and touch responsiveness.
7 inch capacitive touch panel
Open Device Manager. To do this, type Device Manger in Start search, and then click/tap Device Manager entry to launch the same.Alternatively.
Please disconnect the power adapter from your laptop.Flip the laptop over and remove the battery.
Start by removing 4 round screw covers on the outer corners of the bezel.
Proceed with removing 8 bezel screws located under the screw covers.
Open Device Manager. To do this, type Device Manger in Start search, and then click/tap Device Manager entry to launch the same.Alternatively.
Restart Android Device. Before rushing into any other troubleshooting procedure,
Remove Memory Card & SIM Card. Sometimes, faulty memory card or SIM card should take the blame.
Specifications of 7 inch touch panel:
7 Projected Capacitive touch screen by details:
| 7 Inch Projected Capacitive Touch Panel | |
| Model Number | CDZ070GG032 |
| Type | PCAP |
| Structure | Glass+Glass |
| Cover Glass Dimension | 172.40±0.2*119±0.2*0.7±0.2MM |
| Sensor Size | 164.95±0.2*99.35±0.2*0.55±0.2MM |
| Cover Lens VA | 155±0.2*87±0.2MM |
| ITO Glass | 0.55MM |
| Cover Glass | 0.7MM |
| Total Thickness | 1.42±0.1MM |
| Surface Hardness | ≥6H |
| Transparency | ≥90% |
| Operating Temperature | –20℃~70℃ ≤85%RH |
| Storage Temperature | –30℃~80℃ ≤85%RH |
| IC | GSL |
| Interface of CTP | 12C |
| Touch Points | 5-10 points |
| Touch Accuracy | ±1MM |
| Linearity | ±1MM |
| OEM/ODM | we can make this product as per your design and put your logo on |
| MOQ | 10pcs |
| Sample Lead Time | 12 working days |
| Mass Producyion Lead Time | 2-4 weeks normally, it depends on your order quantity |
| Payment Terms | sample: by paypal or western union mass production order: T/T to our company bank account, 50% deposit, 50% balance before shipment |
| Package | plastic tray or anti static foam or paper card or vacuum bag or carton |
| Warranty | 12 months |
4 Telling you about company profile.
Fujian WIWO Technology Co., Ltd. is a professional manufacturer, researcher and designer of Industrial Projected Capacitive Touch Panel / Screen, which has been certificated by IATF16949:2016,ISO9001:2015,REACH,RoHs and ISO14001. Our major product range includes Glass + Glass, Glass + Film, Glass + film + film, full lamination, 3D touch screen and large size touch screen. We have hundreds of dust-free work shop1000 square meters and thousands of dust-free plant 2200 square meters. Meanwhile we use the advanced equipments from Japan and Taiwan to secure the Best Quality for our customers.
5 Packing
1) Wrap in air bubble film
2) Put into foam box
3) Packed with extra carton box, which make sure the goods safety in transportation.
4) We accepted Customized package.
FAQ
Q:Why choose WIWO TOUCH?
A:1)Many years industrial experience and involved main markets all over the world.
2)Dedicated and professional sales team will offer you 24 hours online and immediate service.
3)Precise and advantage equipment.
4)High quality and sensitivity.
5)Many kinds of products with all size.
Q:How long is the warranty period?
A:Usually 1 year without damaged by people actions.It depends on different products.
Q: Is customization available?
A: Yes, we have strong R&D team for ele, mechanical, customization is welcomed.
Q: Can you provide OEM service?
A: yes, we can provide both OEM and ODM service,can customize products according to the drawings you supply.
Q: What's the after-sales service you can supply?
A: If any problems, you will get our reply within 24 hours. Solution will be offered instantly by our professional and strong technical team.
