ILITEK EETI control board 17 Inch Multi Touch Screen HD-MI LCD display touch panel Capacitive Touch Screen Panel for HMI

ILITEK EETI control board 17 Inch Multi Touch Screen HD-MI LCD display touch panel Capacitive Touch Screen Panel for HMI

The main features of 17 inch capacitive touch screen:
1. Touch performance:Multi-touch, high sensitivity, support with gloves or moisture environment operation.
2. High resolution: Generally with 1280×1024 or 1920×1080 resolution display, the picture is clear and delicate.
3. High brightness (1000+ nits) and AG/AR glass treatment for outdoor environments.
4. G+G (glass + glass) structure: scratch and wear resistance, surface hardness up to 6H-7H, improve service life.
5. Optional IK08-IK10 level, improve impact resistance, suitable for industrial and public equipment.

Product Introduction

ILITEK EETI control board 17 Inch Multi Touch Screen HD-MI LCD display touch panel Capacitive Touch Screen Panel for HMI

touch screen

Specification
Model Number
184ACBL170GG-V1.0
Product Name
17 inch capacitive touch screen
Material
Glass
PET Thickenss
1.8mm
ITO Glass Thickness
0.7mm
Other Tolerance
±0.2mm
FPC
10PIN
Interface Type
USB
Transmittance
≥85%
surface hardnsee
6H
Operating Environment
-10℃~+60℃,≤85%RH
Storange Environment
-10℃~+65℃,≤85%RH
Customized Function
Logo AR AF AG and so on
Touch points
Multi Point Touch

Model Number
184ACBL170GG-V1.0
Application
Industrial display screen, armarium display screen
Interface
USB
Type
Capacitive
Length
377mm
Diagonal Screen Size
17 inch
Width
309mm
Features
≤ IK 10
Drive IC
ILI2302
Screen Size
17 inch
Communication interface
USB
Touch Points
Multi Point Touch
Cover Glass Dimension
377±0.3*±309±0.3mm
Cover Lens VA
338.92±0.3*±271.44±0.3mm
Structure
Cover Lens + ITO Glass+FPC
Interface
USB
Application
Industrial
Customized Function
Logo AR AF AG and so on
Warranty
1 Year
Certificate
RoHS Iso14001 Reach ISO9001
Shipment
DHL FEDEX UPS EMS Ect
Touch points
Multi Point Touch

Product service Support


Customized Service

Support custom size, bezel design and touch screen surface treatment to meet different customer needs.
1. Optional surface treatments such as anti-fingerprint, anti-glare, anti-reflection, and waterproof can significantly improve
the readability, clarity, touch experience, and service life of capacitive touch screens.
2. Optional special coatings, such as anti-fingerprint and anti-bacterial finishes, enhance the user experience and product
hygiene.
3. Frame design can be customized according to customer requirements, easy to integrate into a variety of equipment to meet
different product appearance and functional needs, optional thickness and frame color enhance product flexibility and
adaptability.


Application


Manufacturing Technique
Company Profile
Our Company is a professional manufacturer, researcher and designer of Industrial Projected Capacitive Touch Panel / Screen, which has been certificated by ISO9001:2009/ISO14001:2004. Our major product range includes Glass+Glass, Glass+Film, Glass+film+film, full lamination, 3D touch screen and large size touch screen. We have hundreds of dust-free work shop1000 square meters and thousands of dust-free plant 2200 square meters. Meanwhile we use the advanced equipments from Japan and Taiwan to secure the Best Quality for our customers.

Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
FAQ
1. who are we?
We are based in Fujian, China, start from 2016,sell to Domestic Market(50.00%),North America(20.00%),Western Europe(18.00%),Northern Europe(7.00%),Oceania(5.00%). There are total about 51-100 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
projected capacitive touch panel,projected capacitive touch screen,industrial control touch screen,smart home touch screen,projected capacitive multi touch panel

4. why should you buy from us not from other suppliers?
Our Company is a professional manufacturer of Industrial Touch Panel and Screen. We have been certificated by ISO9001:2015 & IIATF 16949:2016. Meanwhile we use the advanced equipments from Japan and Taiwan to secure the Best Quality for our customers.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW;
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,L/C,PayPal,Western Union,Cash;
Language Spoken:English,Chinese,Italian
